VoiceLift Lite Microphone System New

Complete Microphone System for Classroom Voice Amplification

Key Features

Complete high-performance voice reinforcement system for instructional spaces
Advanced RF wireless technology provides superior sound quality, increased reliability, and long-range transmission
Supports up to two microphones simultaneously per VoiceLift System
Two-channel stereo amplifier delivers clear sound for classroom instruction
Compact full-range SM 3 SpeedMount® surface mount speakers for optimal voice intelligibility

The Extron VoiceLift Lite Microphone System

Model	Version Description	Part #
VLSL 3001	Single Pendant VoiceLift Lite System	42-380-01
VLSL 3002H	Pendant and Handheld VoiceLift Lite System	42-380-03

The Extron VoiceLift® Lite System is a complete voice amplification system designed for instructional spaces where voice reinforcement is needed. It uses secure wireless technology in a dedicated spectrum, delivering clear voice reinforcement with reliable performance and reduced interference. Each system includes all the components necessary to distribute the instructor’s voice evenly throughout the classroom, including a wireless microphone system, MPA 152 Plus amplifier, a pair of SM 3 speakers, VoiceLift Pro Port Adapter, mounting hardware, and cable. The system makes it easy to deliver consistent speech intelligibility that helps students hear and engage more effectively throughout the entire space.

Advanced Wireless Technology

VoiceLift Lite uses advanced radio frequency technology operating in a spectrum reserved exclusively for voice communications, providing reliable classroom audio without the limitations of infrared systems. Unlike infrared technology, it is not affected by environmental conditions such as sunlight, windows, or fluorescent lighting.

Pairing technology creates a dedicated connection between each microphone and receiver, preventing interference from microphones in adjacent classrooms. VoiceLift Lite operates independently of Wi-Fi, Bluetooth®, interactive whiteboards, and projector wireless technologies, ensuring dependable performance without disrupting other systems.

With distances operating up to twice that of infrared systems, VoiceLift Lite provides greater flexibility for instructors. Because the technology does not require line of sight, microphones can be worn comfortably in a variety of ways while maintaining consistent audio performance throughout the room.

Plug-and-Play Integration

The VoiceLift Lite Receiver integrates quickly and easily with the MPA 152 Plus stereo amplifier using the VLPA 1 VoiceLift Pro Adapter. The compact receiver, adapter, and amplifier mount conveniently with included ZipClip® mounting hardware, while SM 3 surface mount speakers include SpeedMount® hardware for fast installation. All required cables are included, simplifying deployment and reducing installation time.

Flexible Microphone Support

VoiceLift Lite supports up to two microphones, making it ideal for team teaching, guest instructors, or student participation. Both microphone models feature rechargeable batteries that provide more than eight hours of operation and charge conveniently in a dual-microphone charging base.

Designed for everyday classroom use, the lightweight pendant microphone includes an adjustable lanyard and can be worn around the neck or clipped to clothing. For enhanced classroom support, the pendant microphone also offers an Instant Alert features that allows an instructor to discreetly request assistance with the push of a button when used with an optional MediaLink Plus controller or IPCP Pro xi control processor.

The handheld microphone features an integrated anti-roll collar that helps prevent it from rolling off desks and other flat surfaces.

Complete System

VoiceLift Lite helps ensure every student can hear instruction clearly, from the front row to the back of the room. By delivering consistent voice reinforcement throughout the learning space, the system supports student engagement while reducing vocal strain on instructors. The complete system includes the following components:

VLM 3001 VoiceLift Pro Single Pendant Microphone Kit or VLM 3002H VoiceLift Pro Pendant and Handheld Microphone Kit
MPA 152 Plus Amplifier
SM 3 Surface Mount Speakers (pair) with mounting plates
ZipClip Mounting Kit and ZipClip Caddy
VLPA 1 VoiceLift Pro Port Adapter
100’ SPK 18 Speaker Cable

Features

Complete high-performance voice reinforcement system for instructional spaces

Advanced RF wireless technology provides superior sound quality, increased reliability, and long-range transmission — Pairing creates an exclusive relationship between the microphones and the receiver, preventing interference between classrooms

Supports up to two microphones simultaneously per VoiceLift System

Two-channel stereo amplifier delivers clear sound for classroom instruction —

Compact, energy-efficient MPA 152 Plus stereo amplifier
Ecofficient® Level 3 amplifier with automatic standby mode after 25 minutes of inactivity to lower energy costs

Compact full-range SM 3 SpeedMount® surface mount speakers for optimal voice intelligibility —

Provides wide coverage and frequency range of sound throughout the instructional space
Fast, secure installation and mounting
Hidden locking mechanism to secure in place with a unique key to deter theft

Durable and reliable microphones to withstand rigors of daily use —

Lightweight pendant microphone features an adjustable lanyard to be worn around the neck or clipped to clothing
Handheld microphone features an integrated anti-roll collar to avoid rolling off flat surfaces
Both microphone models have high-capacity rechargeable batteries for over 8 hours of talk time, and a charging base supports up to two microphones

Instant Alert feature on pendant microphone — Enables fast, discreet assistance at the push of a button for an instructor when used with an optional MediaLink Plus controller or IPCP Pro xi control processor

ZipClip® 400 mounting capability — Receiver, adapter, and amplifier components can be quickly and securely mounted behind a display, to rack rails, tables, shelves, and lecterns

OPTIONAL ACCESSORIES
	PPC 25	Priority Page Controller
	VCM 200 D	Volume and Mute Controller - Decorator-Style Wallplate

OPTIONAL ACCESSORIES

PPC 25

Priority Page Controller

VCM 200 D

Volume and Mute Controller - Decorator-Style Wallplate

RELATED PRODUCTS
	MPA 152 Plus	Stereo Amplifier - 15 Watts Per Channel
	SM 3	SpeedMount Compact Full-Range Surface Mount Speakers
	ZipClip 400	Mounting Kit for 1/8, 1/4, and 1/2 Rack Width Products

SIMILAR PRODUCTS
	VLC 302	VoiceLift Pro Charging Station
	VLH 302	VoiceLift Pro Handheld Microphone
	VLP 302	VoiceLift Pro Pendant Microphone
	VLR 302	VoiceLift Pro Receiver
	VoiceLift Pro Microphone	High Performance Wireless Microphone
	VoiceLift Pro Microphone System	Complete Microphone System for High Performance Classroom Voice Amplification

SIMILAR PRODUCTS

VLC 302

VoiceLift Pro Charging Station

VLH 302

VoiceLift Pro Handheld Microphone

VLP 302

VoiceLift Pro Pendant Microphone

VLR 302

VoiceLift Pro Receiver

VoiceLift Pro Microphone

High Performance Wireless Microphone

VoiceLift Pro Microphone System

Complete Microphone System for High Performance Classroom Voice Amplification

Specifications

VoiceLift Pro System Kit

Overall system

Operating range

40' x 40' minimum coverage

Reception area

1600 square feet (148.6 square meters) minimum

Radio frequency

1900 MHz

Vibration

ISTA 1A in carton (International Safe Transit Association)

Regulatory compliance

EMI/EMC

CE, FCC Class B

Environmental

Complies with the appropriate requirements of RoHS and WEEE

Product warranty

Product

3 years parts and labor

Microphone battery

90 days

VLP 302 Pendant Microphone

User controls

Power, volume, and function

Audio input

Number/signal type

1 mono, via integrated MEMS microphones
1 mono, unbalanced, via auxiliary mic input jack

Connector

(1) 3.5 mm mini audio jack (tip = audio signal/bias voltage, sleeve = GND)

Batteries

Number/type

1 AA size NiMH or alkaline battery

Operating life

Rechargeable 2400 mAh NiMH batteries: min. 8 hours, continuous use
Alkaline batteries: min. 8 hours, continuous use

Recharging time

~5 hours for a 2400 mAh NiMH battery

Enclosure dimensions

3.0" H x 1.47" W x 1.2" D*
(7.6 cm H x 3.7 cm W x 3.0 cm D*)
*Depth includes clip. Depth without clip = 0.9", 2.3 cm

Product weight

1.2 oz (34 g) without battery
2.2 oz (62 g) with battery

Regulatory compliance

Safety

UL, c-UL, FCC Class B

Accessibility

Section 508 of the Rehabilitation Act (29 U.S.C. 794d)

VLH 302 Handheld Microphone

User controls

Power, volume, and link

Audio input

Number/signal type

1 mono, via integrated MEMS microphones
1 stereo, unbalanced, via auxiliary line level input jack

Connectors

(1) 3.5 mm mini audio jack (tip = left channel audio, ring= right channel audio, sleeve = GND)

Batteries

Number/type

1 AA size NiMH or alkaline battery

Operating life

Rechargeable 2400 mAh NiMH batteries: min. 8 hours, continuous use
Alkaline batteries: min. 8 hours, continuous use

Recharging time

~5 hours for a 2400 mAh NiMH battery

Enclosure dimensions

8.0" H x 1.8" (max) diameter
(20.2 cm H x 4.6 cm [max] diameter)

Product weight

4.0 oz (113 g) without battery
5.0 oz (142 g) with battery

Regulatory compliance

CE, FCC Class B, UL, c-UL

Accessibility

Section 508 of the Rehabilitation Act (29 U.S.C. 794d)

VLR 302 Receiver

User controls

2 normally open relays
1 RS-232 port (38400 baud, 8 data bits, 1 stop bit, no parity) via RJ-45
1 USB

Mounting

Rack, ceiling, or wall mountable

Power input requirements

12 VDC, 0.2 A

Enclosure dimensions

1.66" H* x 2.15" W x 4.50" D
(4.2 cm H x 5.5 cm W x 11.4 cm D)
*Height is measured out from the mounting surface.

Product weight

0.25 lbs (0.11 kg)

Regulatory compliance

CE, FCC Class B, UL, c-UL

VLC 302 Charging Station

External power supply

110 VAC to 130 VAC, 50-60 Hz, external; to 5 VDC, 2.6 A, regulated
USB Micro B

Power input requirements

5 VDC, 0.5 A

Enclosure dimensions

1.5" H x 4.4" W x 3.4" D
(3.9 cm H x 11.3 cm W x 8.6 cm D)

Product weight

0.66 lbs (0.3 kg)

Regulatory compliance

CE, UL, c-UL

Environmental

Complies with the appropriate requirements of ENERGY STAR^® (ENERGY STAR qualified power supply, efficiency level VI).

MPA 152 Plus

Audio

Voltage gain

Balanced

25x (28 dB)

Unbalanced

50x (34 dB)

Stereo channel separation

>60 dB @ 1 kHz

CMRR

74 dB (typical) @ 1 kHz

Bass adjustment

±10 dB @ 80 Hz (reference) to 1 kHz (2 dB tolerance)

Treble adjustment

±10 dB @ 10 kHz (reference) to 1 kHz (2 dB tolerance)

Audio input

Number/signal type

1 stereo, balanced/unbalanced input
2 stereo, unbalanced inputs
(The three inputs are individually buffered and summed together.)

Connectors

(1) 3.5 mm captive screw connector, 5 pole (main input)
(1) 3.5 mm mini audio jack (tip, ring, sleeve)
1 pair female RCA

Impedance

>10k ohms unbalanced/balanced, DC coupled

Maximum level

RCA and TRS inputs

+9 dBV (unbalanced) at 1% THD+N

Captive screw input

+12 dBu (balanced) at 1% THD+N

Input sensitivity

Balanced

-8 dBu

Unbalanced

-16 dBV

Input signal detection threshold

RCA and mini audio jacks: -53 dBV (2.24 mV) ±3 dB, unbalanced
Captive screw connector: -46 dBu (3.88 mV) ±3 dB, balanced

NOTE	0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV ≈ 2 dBu

Audio output

Number/signal type

1 stereo or 2 mono (2 channels total)

Connector

(1) 5 mm captive screw connector, 4 pole

Load impedance

4 ohms, minimum

Amplifier type

Class D

Output power

8 watts rms per channel, 8 ohms, 1 kHz, 1% THD
15 watts rms per channel, 4 ohms, 1 kHz, 1% THD

Frequency response

20 Hz to 20 kHz, +1/-3 dB @ 8 ohms

THD + Noise

<0.1% -3dB below clipping @ 1 kHz, 8 ohm load

S/N

90 dB, 20 Hz to 20 kHz, unweighted

Damping factor

>100 at 8 ohms

Communications — amplifier

Control port

(1) 3.5 mm captive screw connector, 3 pole

Pin configuration

Pin 1 = +10 VDC, 50 mA (max.), pin 2 = volume/mute (variable voltage), pin 3 = GND

Volume control voltage range

0 V (mute) to 10 V (maximum volume)

General

Power supply

External
Input: 100-240 VAC, 50-60 Hz
Output: 12 VDC, 2 A, 24 watts

Power consumption and thermal dissipation

		115 VAC, 60Hz				230 VAC, 50Hz
		AC Line Current	AC Power Consumed	Thermal Dissipation		AC Line Current	AC Power Consumed	Thermal Dissipation/
Condition		A	W	W	BTU/hr	A	W	W	BTU/hr
Active (1/8 power), all channels driven	8Ω	0.1	5.8	3.8	13	0.1	5.9	3.9	13
	4Ω	0.1	7.8	4.1	14	0.1	7.8	4.1	14



Quiescent (idle)		0.1	3.4	3.4	12	0.1	3.4	3.4	12
Standby		<0.1	<1	<1	<3	<0.1	<1	<1	<3

Ambient temperature/humidity

Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing

Cooling

Convection, no vents

Mounting

Rack mount

Yes, with optional 1U rack shelf or back of rack mounting kit

Furniture mount

Yes, with optional mini under desk mounting kit

Pole mount

Yes, with optional pole mounting kit

Enclosure type

Metal

Enclosure dimensions

1.7" H x 4.3" W x 3.0" D (1U high, quarter rack wide)
(4.3 cm H x 10.9 cm W x 7.6 cm D)
(Depth excludes connectors.)

Product weight

0.6 lbs (0.3 kg)

Regulatory compliance

CE, C-tick, c-UL, FCC Class B, ICES, KC, RoHS, UL VCCI, WEEE
UL rated for use in plenum airspaces: meets UL 2043 for heat and smoke release, excluding the power supply; meets UL/IEC 62368-1 for safety.
Complies with the appropriate requirements of CEC, Ecofficient Level 3 EU code of conduct

Product warranty

3 years parts and labor

Everlast power supply warranty

7 years parts and labor

NOTE	All nominal levels are at ±10%.

NOTE	Specifications are subject to change without notice.

SM 3 Speakers

Audio/acoustic and electrical

Speaker type

1-way, full range, indoor surface mount speaker

Frequency range

100 Hz to 20 kHz, -10 dB, full space

Power capacity

15 W (rms) continuous pink noise (per IEC 60268-5)
30 W (rms) continuous program

Nominal sensitivity

83 dB SPL, 1 W, 1 m, full space

Nominal coverage angles

Horizontal: 120° (1 kHz - 4 kHz, weighted 2 kHz - 4kHz)
Vertical: 130° (1 kHz - 4 kHz, weighted 2 kHz - 4kHz)

Nominal impedance

8 ohms

Driver

(1) 3" (76.2 mm) paper cone

Input connectors

Speaker

2 recessed pins

Mounting plate

(1) 10 mm Euro-style captive screw terminal block, 2 pole

General

Package

2 speakers (1 pair) with mounting kit

Ambient temperature/humidity

Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing

Mounting

Wall mountable with included mounting plates (0° and 10°)

NOTE	Speaker mounting angle is fixed at 0° or 10° from vertical based on the mounting plate used.

Enclosure type

Plastic, trapezoidal, with molded grille and front bass reflex port

Enclosure outer dimensions

With 0° mounting plate

8.75" H x 5.75" W x 4.0" D
(22.2 cm H x 14.6 cm W x 10.2 cm D)

With 10° mounting plate

8.9" H x 5.75" W x 5.0" D
(22.6 cm H x 14.6 cm W x 12.7 cm D)

Product weight

Single: 2.0 lbs (0.9 kg)

Regulatory compliance

Safety

Environmental

Complies with the appropriate requirements of RoHS, WEEE.

Product warranty

5 years parts and labor

NOTE	All nominal levels are at ±10%.

NOTE	Specifications are subject to change without notice.

ZipClip 400 and ZipCaddy 400

Mounting

Rack rail mount

Yes, with required hardware

Furniture mount

Yes, with included hardware

Load bearing

Vertical mounting

9.5 lbs (4.3 kg)

Horizontal mounting

5.0 lbs (2.27 kg)

NOTE	Supports eighth-rack, quarter-rack, and half-rack width products.

Enclosure

Enclosure dimensions

ZipClip 400

9.5" H x 4.6" W x 0.6" D
(241 mm H x 116 mm W x 15 mm D)

ZipCaddy 400

8.6" H x 4.4" W x 0.4" D
(218 mm H x 111 mm W x 10 mm D)

Enclosure material

High impact plastic

Product weight

0.3 lbs (0.1 kg) per each clip and plate pair

(6645-D1)

Advanced Wireless Technology

Plug-and-Play Integration

Flexible Microphone Support

Complete System

Features

Specifications

Diagram
