New Extron Extended Distance Twisted Pair Receivers

Send Signals Much Farther: 1500'

The MTP 1500RL Series is Extron's line of twisted pair receivers for AV systems with extended distance signal transmission requirements. There are three models in the series:

The MTP 1500RL 15HD A SEQ works with MTP Series transmitters to send high resolution video and audio signals 1,500 feet (450 meters) or more over a single CAT 5-type cable.

The MTP 1500RL 15HD RS and MTP 1500RL 15HD RS SEQ work with MTP Series transmitters to send high resolution video and RS-232 signals 1,500 feet (450 meters) or more over a single CAT 5-type cable.

The MTP 1500RL extended distance receivers are compatible with resolutions up to 1920x1200 WUXGA, and feature separate continuously variable level and peaking adjustments that precisely optimize image quality for various cable lengths. Each receiver also offers an additional female RJ-45 buffered output, enabling up to eight receivers to be connected in series, reducing the number of parallel cable runs required. The SEQ models in the series feature independent skew compensation adjustments for each color.

MVC 121 Plus Diagram
MVC 121 Plus Diagram
