HAE 100 4K and HAI 100 4K

HDMI Audio De-Embedder and Embedder

The Extron HAE 100 4K audio de-embedder and HAI 100 4K audio embedder are high performance products. The HAE 100 4K extracts audio from an HDMI signal, including audio from 4K sources, and provides outputs for stereo and dual mono analog audio signals, as well as digital multi-channel or two-channel S/PDIF audio. The HAI 100 4K embeds either two-channel analog audio, or S/PDIF digital audio in two-channel or multi-channel formats onto the HDMI output signal. The HAE 100 4K and HAI 100 4K are HDCP compliant, support data rates up to 10.2 Gbps, and are compatible with video resolutions up to 4K. Both products are equipped with several integrator-friendly features such as EDID Minder®, HDMI input cable equalization, comprehensive LED status display, and a compact enclosure size.



Key Features

  • HDMI audio de-embedding with analog stereo or dual mono, and digital S/PDIF audio outputs - HAE 100 4K
  • HDMI audio embedding with stereo analog or digital S/PDIF audio inputs - HAI 100 4K
  • Supports computer and video resolutions up to 4K
  • Supported HDMI specification features include data rates up to 10.2 Gbps, Deep Color up to 12-bit, 3D, and CEC pass-through
  • HDCP compliant
  • User-selectable HDCP authorization
  • Selectable output format
  • EDID Minder
  • Automatic HDMI input cable equalization to 50 feet (15 meters) at 4K, or 100 feet (30 meters) at 1080p/60 when used with Extron HDMI Pro cables
  • Rack-mountable 1" (2.5 cm) high, quarter rack width metal enclosure
HAE 100 4K diagram
The HAE 100 4K provides HDMI audio de-embedding for an audio system.
HAI 100 4K diagram
The HAI 100 4K embeds audio from a sound system onto the HDMI signal for routing to a display.
