Audio Signal Routing and Control

4x4 line level audio matrix mixer
DSP audio signal processing
Three digital input ports plus RS-232 and USB ports

Digital Audio Signal Processing

Fixed, low latency DSP processing
Intuitive Graphical User Environment
Wide selection of audio DSP tools

More

USB configuration port for easy configuration via DSP Configurator software without having to access the processor's rear panel
Close
More

Four balanced/unbalanced line level inputs
Close
More

Rack-mountable 1U, quarter rack width metal enclosure
Close
More

Three digital input ports allow external switches and sensors to be connected to the mixer for remote triggering
Close
More

RS-232 control port allows configuration and control system integration
Close

More

Presets

16 presets store entire DSP configuration or selected DSP settings
Close
More

Gain Stages

4 gain stages across input-to-output paths
Gain control at mix points
Close
More

Filters

3 filters per input
9 filters per output
High pass
Low pass
Shelving
Parametric EQ
Close
More

Dynamics

1 compressor per input
1 limiter per output
Close
More

Ducking

1 ducking processor for mic/line inputs, multiple priority levels
Close

DMP 44 LC

Digital Matrix Processor

The Extron DMP 44 LC Digital Matrix Processor is a compact 4x4 audio matrix mixer featuring a digital signal processing platform for audio signal routing and control. The DMP 44 LC features four line level inputs and outputs, all balanced or unbalanced. It offers several audio DSP tools for mixing, routing, and room optimization with quick and intuitive configuration using the DSP Configurator™ Software, allowing the DMP 44 LC to be installed in very little time. The DMP 44 LC is ideal for presentation applications that require line level audio matrix mixing with DSP in a small form factor.
